DV-3100

AI in the Box

ㆍAI in the Box with IDIS Solution Suite
ㆍCompatible with IDIS Deep-Learning Analytics (IDLA)
ㆍAnalytics available with ISS IDLA up to 64 IP cameras
ㆍ4U rack mount chassis

Compare product
Category: Tag:

Description

System
IDIS Solution SuiteCompatible with IDLA VA Service
Version 3.0.0 or Higher
Network Connection2 GbE RJ-45 Ports (1000Base-T)
Channels available for AnalytiUp to 64ch in condition of 640×360@5ips video input
IDLA Processing UnitNVIDIA RTX2060, 8GB
Operating SystemMicrosoft® Windows Embedded Standard 8
ProcessorIntel® I7-7700, 3.6GHz
MemoryDDR4 PC-19200, 8GB
Video Outputs1 HDMI, 1 DP, 1 VGA
USB6 ( 2 Front USB 2.0 + 2 Back USB 3.0 + 2 Back USB 2.0)
Mechanical
Form Factor4U RACK Mount Chassis
Dimensions (W x D x H)440mm x 177mm x 462mm (17.3″ x 7.0″ x 18.2″)
Shipping Dimensions (W x D x H590mm x 350mm x 700mm (23.2″ x 13.7″ x 27.6″)
Weight14.0kg (30.9 lbs.)
Electrical
Power InputAC 100-240 V, 50/60Hz, 5.5 – 2.5A
Power SupplySingle Power
Power Consumption350W
Environmental
Operating Temperature0°C to 40°C (32°F to 104°F)
Operating Humidity0% to 90%
General
CertificationsFCC, CE, CB, UL, KC

Downloads

Firmware
Latest Version
ManualNLENFR
Quick Guide
DatasheetNLENFR
Latest version
A&E specificationsNLENFR
Architectural and Engineering Specifications
BIM
Building Information Model

Information request
