| Video |
| Image Sensor |
1/2.8″ CMOS |
| Max. Resolution |
2592 x 1944 |
| Scanning Mode |
Progressive Scan |
| Lens type |
Motorized Vari-focal |
| Focal Length |
f=3.2-10.5mm |
| Aperture |
F1.6 – 3.3 |
| Iris Control |
P-Iris |
| Angular Field of View |
[4:3 mode]
Wide : 98.9º(H) 71.1º(V) 133.8º(D)
Tele : 28.2º(H) 21.2º(V) 35.3(D)[16:9 mode]
Wide : 98.9º(H) 52.2º(V) 117.9º(D)
Tele : 28.2º(H) 15.9º(V) 32.4º(D) |
| Pan/Tilt Range |
Pan: -180° ~ 180°, Tilt: -5° ~ 70°, Rotate: -180° ~ 180° |
| Min. Illumination |
COLOR : 0.13 lux @ F1.6
B/W : 0 lux (IR LED on) |
| Dynamic Range |
120dB (True WDR) |
| Electronic Shutter Speed |
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day & Night |
IR cut filter with auto switch |
| IR Distance (LEDs) |
50m (6ea) |
| Image Setting |
Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control) |
| Backlight Compensation |
– |
| Mirroring / Pivot |
Horizontal / Vertical / Pivot |
| Image Stabilizer |
– |
| De-fog |
Yes |
| Privacy Masking |
8 Zones |
| Intelligent Video |
Video Motion Detection, Active Tampering Alarm, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection |
| Video Out |
– |
| Network |
| Video Compression |
H.265, H.264 (MP), M-JPEG |
| Intelligent Codec |
Yes |
| Bitrate Control |
H.265 – CBR / VBR, H.264 – CBR / VBR |
| Audio Compression |
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law |
| Two-way Audio |
Yes |
| IP Camera Protocol |
DirectIP 2.0, ONVIF Profile S/T |
| Max. Frame Rate |
4:3 mode : 30ips : 2592 x 1944(WDR)
16:9 mode : 30ips : 2592 x 1456(WDR) |
| Supports Resolution |
4:3 : 2592×1944, 1920×1440, 1280x960x 640×480
16:9 : 2592×1456, 1920×1080, 1280×720, 640×360 |
| Multi-Video Streaming |
Quadruple streaming |
| Network Protocols |
DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Security |
Digest authentication, Password Protection, User access log, IP Filtering, IEEE802.1x(EAP-TLS), Chained Fingerprint, SSL Encryption, HTTPS Encryption |
| Ethernet |
RJ45(10/100BASE-T) |
| Recording Session Buffer (NLTSrec) |
Yes (Up to 60MB) |
| Edge Storage |
Micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| Alarm & Event |
| Trigger Event |
Motion Detection, Alarm in, Audio detection, Tampering, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection |
| Event Notification |
Remote S/W, Email (with Image) |
| Audio Alarm |
Yes |
| Audio In / Out |
1(Built In MIC)+1 / 1 |
| Alarm In / Out |
1 / 1 |
| Environmental |
| Vandal Resistance |
IK10 |
| Outdoor Ready |
IP67, Heater |
| Operating Temperature |
-40°C ~ 55°C ( -40°F ~ 131°F)
*Starting up at above -20°C (-4°F) |
| Operating Humidity |
0% ~ 90% |
| Electrical |
| Power Source |
12VDC, PoE(IEEE 802.3af Class 3) |
| Power Consumption |
12V=, 1.1A, 13.2W
PoE, IEEE 802.3af(Class 3), 11.5W |
| Approval |
FCC, CE, KC |
| Mechanical |
| Dimensions (Ø x H) |
Ø135mm x 98.5mm (Ø5.31” x 3.88”) |
| Weight |
830g (1.83lb) |
