Video |
Beeld Sensor | 1/2.8″ CMOS |
Max. Resolutie | 1920 x 1080 |
Scanning Mode | Progressive Scan |
Lens type | AF Zoom Lens |
Brandpuntsafstand | f=5.3 – 64mm (12x) |
Opening | F1.6 – 2.8 |
Iris Control | DC Auto Iris (HALL SENSOR) |
Kijkhoeken | Wide : 58,2º(H), 34º(V), 65,3º(D) Tele : 4,83º(H), 2,8º(V), 5,7º(D) |
Min. Verlichting | KLEUR : 0.1 lux @ F1.6 Z/W : 0.01 lux @ F1.6 |
Dynamisch bereik | 120dB (True WDR) |
Elektronisch Shutter Snelheid | Auto / Handmatig (1/30 ~ 1/10000), Anti-Flicker, Slow Shutter (1~1/7.5, 1/15) |
Dag & Nacht | IR cut filter met automatische schakelaar |
IR Afstand (LED’s) | – |
Beeld Instelling | Exposure, Witbalans, Zelfinstellende videomodus (Scherpte, Contrast, Kleuren, Helderheid) |
Backlight Compensatie | Aan / Uit |
Mirroring / Pivot | Horizontaal / Verticaal |
Beeldstabilisatie | Ja (EIS) |
Privacy Masker | 8 Zones |
Intelligent Video | Video Motion Detection, Active Tampering Alarm |
Auto Tracking | No |
Video Uit | – |
Pan/Tilt/Roteren |
Pan Bereik | 360° (Eindeloos) |
Pan Snelheid | 0,02~150°/sec (preset 150°/sec) |
Tilt Bereik | 180° (0~180°) |
Tilt Snelheid | 0,02~150°/sec (preset 150°/sec) |
Preset | 256ea |
Netwerk |
Video Compressie | H.265, H.264(MP), M-JPEG |
Intelligent Codec | Ondersteund |
Bitrate Control | H.265 – CBR / VBR, H.264 – CBR / VBR |
Audio Compressie | – |
Two-way Audio | – |
IP Camera Protocol | DirectIP™ Modus : DirectIP 2.0, ONVIF Profile S |
Max. Frame Rate | DirectIP™ Modus : 30ips : 1920 x 1080(WDR) |
Ondersteunt Resolutie | 1920×1080, 1280×720, 640×360, 352×240 |
Multi-Video Streaming | DirectIP™ Modus : Quadruple streaming |
Netwerk Protocollen | DirectIP™ Modus : DirectIP 2.0 Protocol, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
Beveiliging | DirectIP™ Modus : SSL Encryptie, Multi-User Authority, IEEE 802.1x IP Filtering, HTTPS |
Remote Access Client | DirectIP™ Mode : DirectIP™ NVR connection, IDIS Web, IDIS Mobile (Plus), IDIS Solution Suite, IDIS Cloud Manager |
Ethernet | RJ45(10/100BASE-T) |
Opnamesessie Buffer (NLTSrec) | Ja (tot 60MB) |
Edge Opslag | micro SD/SDHC/SDXC, Smart Failover (tot 256GB) |
Alarm & Event |
Trigger Event | Motion Detection, Alarm in, Tampering, Trip Zone |
Event Notificatie | Remote S/W, Email (met plaatje) |
Audio In/ Uit | – |
Alarm In / Uit | 1 / 1 |
Omgeving |
Vandaalbestendig | – |
Outdoor Ready | – |
Bedrijfstemperatuur | -10°C ~ +50°C (14°F ~ +122°F) *Opstarten boven 0°C (32°F) |
Bedrijfsvochtigheid | 0% ~ 90% |
Elektrisch |
Voeding | 12VDC, PoE(IEEE 802.3af Class 3) |
Stroomverbruik | 12VDC : 9.2W PoE (IEEE 802.3af Class 3) : 10W |
Goedkeuring | FCC, CE(50130-4), KC, UL |
Mechanisch |
Afmetingen (Ø x H) | Ø155mm x 158,1mm (Ø6,1″ x 6,22″) |
Gewicht | 1,0 kg |
