Video |
BeeldSensor | 1/2.7″ CMOS |
Max. Resolutie | 1920 x 1080 |
Scanning Mode | Progressive Scan |
Lens type | Vari-focal |
Brandpuntsafstand | f=3.3 – 10mm |
Opening | F1.3 – 2.5 |
Iris Control | DC Auto Iris |
Kijkhoeken | Wide : 108,2º(H), 56,2º(V), 129,3º(D) Tele : 35,4º(H), 19,8º(V), 40,5º(D) |
Pan/Tilt Range | Pan: -167° ~ 167°, Tilt: 0° ~ 70°, Rotate: -176° ~ 176° |
Min. Verlichting | KLEUR : 0.1 lux @ F1.3 Z/W : 0.02 lux @ F1.3 |
S/N Ratio | Meer dan 45dB |
Dynamische Range | Meer dan 70dB |
Electronische shuttersnelheid | Auto / Handmatig (1/30 ~ 1/8000), Anti-Flicker, Slow Shutter(1/7.5,1/15) |
Dag & Nacht | IR cut filter met automatische schakelaar |
IR Afstand (LEDs) | – |
Beeld instellingen | Instelbare Exposure, Wit Balans, Scherpte |
Digitale Ruisonderdrukking | Instelbaar 2DNR |
Backlight Compensatie | Aan / Uit / HSBLC |
Mirroring / Pivot | Horizontaal / Verticaal / Pivot |
Privacy Masker | 16 Zones |
Intelligent Video | Video Motion Detectie, Active Tampering Alarm, Trip Zone |
Video Uit | 1 Terminal Block |
Netwerk |
Video Compressie | H.264(MP), M-JPEG |
Intelligent Codec | – |
Bitrate Control | H.264 – CBR / VBR |
Audio Compressie | ADPCM 16K, G.726, G.711 u-Law |
Two-way Audio | Ja |
IP Camera Protocol | DirectIP™ Modus : DirectIP |
| Compatibiliteit Modus : IDIS ONVIF Profile S |
Max. Frame Rate | DirectIP™ Mode : 30ips : 1920 x 1080 |
| Compatibility Mode : 30ips : 1920 x 1080 |
Ondersteunt Resolutie | DirectIP™ Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
| Compatibility Mode : 1920×1080, 1280×720, 704×480, 352×240 |
Multi-Video Streaming | DirectIP™ Modus : Quadruple streaming |
| Compatibiliteit Modus : Triple streaming |
Network Protocollen | DirectIP™ Modus : Direct IP Protocol |
| Compatibiliteit Modus : RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
Beveiliging | DirectIP™ Modus : SSL Encryptie |
| Compatibiliteit Modus : Multi-User Authority, IEEE 802.1x IP Filtering, HTTPS, SSL Encryptie |
Remote Access Client | DirectIP™ Modus : DirectIP™ NVR connectie |
| Compatibiliteit Modus : IDIS Web, IDIS Mobile, IDIS Solution Suite |
Ethernet | RJ45(10/100BASE-T) |
Recording Session Buffer (NLTSrec) | Ja (tot 60MB) |
Edge Storage | micro SD/SDHC, Smart Failover (tot 32GB) |
Alarm & Event |
Trigger Event | Motion Detectie, Alarm in, Audio detection, Tampering, TripZone |
Event Notificatie | Remote S/W, Email (met plaatje) |
Audio In/ Uit | Line-in 1ea / Line-out 1ea |
Alarm In / Uit | Ingang 1ea / Uitgang 1ea |
Omgeving |
Vandaalbestendig | IK10 |
Out-door Ready | IP66 |
Bedrijfstemperatuur | -10°C ~ +50°C (+14°F ~ +122°F) *Opstarten boven 0°C (32°F) |
Bedrijfsvochtigheid | 0% ~ 90% |
Elektrisch |
Voeding | 12VDC, PoE(IEEE 802.3af class 2) |
Stroomverbruik | 4,8W |
Goedkeuring | FCC, CE, KC |
Mechanical |
Afmetingen (Ø x H) | Ø160mm x 112mm (Ø6,3″ x 4,41″) |
Gewicht | 0,87 kg (1,92 lb) |
