Video |
Beeld Sensor | 1/2.8″ CMOS |
Max. Resolutie | 1920 x 1080 |
Scanning Mode | Progressive Scan |
Lens type | Gemotoriseerde Vari-focal |
Brandpuntsafstand | f=3.3 – 10mm |
Opening | F1.3 – 2.5 |
Iris Control | DC Auto Iris |
Kijkhoeken | Breedte : 99.8º(H), 52.2º(V), 118.2º(D) Tele : 33.5º(H), 18.6º(V), 38.3º(D) |
Min. Verlichting | KLEUR : 0.1 lux F1.3 Z/W : 0 lux (IR LED ON) |
S/N Ratio | 31.2 dB |
Dynamische Range | 75dB(90dB@Digital WDR) |
Electronische shutter snelheid | Auto / Handmatig (1/30 ~ 1/8000), Anti-Flicker, Slow Shutter(1/7.5,1/15) |
Dag & Nacht | IR cut filter met automatische schakelaar |
IR Afstand (LEDs) | 30 m (24 ea) / White LED (6 ea) |
Beeld Instelling | Instelbare Exposure, Wit Balans, Scherpte |
Digital Ruisonderdrukking | Instelbaar 2DNR |
Backlight Compensation | Aan/ Uit / HSBLC |
Mirroring / Pivot | Horizontaal / Verticaal / Pivot |
Beeld stabilisatie | – |
Privacy Masker | 16 Zones |
Intelligent Video | Video Motion Detectie, Active Tampering Alarm, Trip Zone |
Video Uit | 1 BNC |
Netwerk |
Video Compressie | H.264(MP), M-JPEG |
Bitrate Control | H.264 – CBR / VBR |
Max. Frame Rate | 30fps : 1920 x 1080 |
Audio Compressie | – |
Two-way Audio | – |
IP Camera Protocol | DirectIP™ Modus : DirectIP |
| Compatibiliteit Modus : IDIS ONVIF Profile S |
Ondersteunt resolutie | DirectIP™ Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
| Compatibiliteit Modus : 1920×1080, 1280×720, 704×480, 352×240 |
Multi-Video Streaming | DirectIP™ Modus : Quadruple streaming |
| Compatibiliteit Modus : Triple streaminging |
Network Protocollen | DirectIP™ Modus : Direct IP Protocol |
| Compatibiliteit Modus : RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
Beveiliging | DirectIP™ Modus : SSL Encryptie |
| Compatibiliteit Modus : Multi-User Authority, IEEE 802.1x IP Filtering, HTTPS, SSL Encryptie |
Remote Access Client | DirectIP™ Modus : DirectIP™ NVR connectie |
| Compatibiliteit Modus : IDIS Web, IDIS Mobile, IDIS Solution Suite |
Ethernet | RJ45(10/100BASE-T) |
Edge Storage | – |
Alarm & Event |
Trigger Event | Motion Detectie, Tampering, TripZone |
Event Buffering (Pre & Post) | ja (tot 60MB) |
Event Notificatie | Remote S/W, Email (with Image) |
Pre-recorderd Voice Alert (IDIS protocol) | – |
Audio In/ Uit | – |
Alarm In / Uit | Output 1ea |
Omgeving |
Vandaalbestendig | Ja |
Out-door Ready | IP66 |
Bedrijfstemperatuur | -10°C ~ 50°C ( 14°F ~ 122°F) *Opstarten boven 0°C (32°F) |
Operating Humidity | 0% ~ 90% |
Elektrisch |
Voeding | 12VDC, PoE(IEEE 802.3af class 3) |
Stroom verbruik | 7.2W |
Goedkeuring | FCC, CE, KC |
Mechanisch |
Afmetingen (B x H) | Ø73.5mm x 290.2mm (Ø2.9″ x 11.43″) |
Gewicht | 1.17 kg (2.58 lb) |
