DC-D4831HRX

Rupture de stock

(Nederlands) 4K UHD Gemotoriseerde VariFocus lens Duplex audio Power over Ethernet True Dag & Nacht met ICR Backlight Compensation True Wide Dynamic Range Infrarood Vandaalbestendig IP67

8MP Vandaalbestendige IR Dome Camera met Heater

• Eenvoudige installatie met DirectIP NVR
• 8MP (3840 x 2160) resolutie
• Gemotoriseerde Vari-focal lens (f=2.7 – 13.5mm)
• Micro SD / SDHC / SDXC, Smart Failover
• Two-way audio
• Alarm in / uit
• IK10 / IP67
• PoE (IEEE 802.3af Class 3), 12V DC
• Dag en nacht (ICR)
• IR LED (Afstand : 40m)
• True wide dynamic range (WDR)
• 3-assig mechanisch ontwerp voor installatie
• Ondersteunt ONVIF
• Voldoet aan NDAA
Comparer le produit
Catégorie : Étiquette :

Description

Désolé, cet article est seulement disponible en Néerlandais et Anglais Américain. Pour le confort de l’utilisateur, le contenu est affiché ci-dessous dans la langue par défaut du site. Vous pouvez cliquer l’un des liens pour changer la langue du site en une autre langue disponible.

Video
Beeld Sensor 1/2.8″ CMOS
Max. Resolutie 3840 x 2160
Scanning Mode Progressive Scan
Lens type Gemotoriseerde Vari-focal
Brandpuntsafstand f=2.7 – 13.5mm
Opening F1.8 – 3.32
Iris Control DC Iris
Kijkhoeken Wide : 110,6º(H) 57,3º(V) 134,1º(D)
Tele : 32,6º(H) 18,3º(V) 37,4º(D)
Pan/Tilt Range Pan: -175° ~ 175°, Tilt: 0° ~ 64°, Rotate: -177° ~ 177°
Min. Verlichting KLEUR : 0.2 lux @ F1.8
Z/W : 0 lux (IR LED aan)
Dynamische Range 120dB (True WDR)
Elektronische Shutter Snelheid Auto / Handmatig (1/30 ~ 1/10000), Anti-Flicker, Slow Shutter (1/7.5, 1/15)
Dag & Nacht IR cut filter met automatische schakelaar
IR Afstand (LEDs) 40m (6 ea)
Beeldinstellingen Instelbare Exposure, Witbalans, Scherpte
Digitale Ruisonderdrukking Instelbaar 2DNR/3DNR
Backlight Compensatie Aan / Uit
Privacy Masker 8 Zones
Intelligent Video Video Motion Detectie, Active Tampering Alarm, Trip Zone
Netwerk
Video Compressie H.265, H.264(MP), M-JPEG
Intelligent Codec Ondersteund
Bitrate Control H.264 – CBR/ VBR, H.265 – CBR / VBR
Audio Compressie ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law
Two-way Audio Ja
IP Camera Protocol DirectIP™ Modus : DirectIP 2.0, ONVIF Profile S
Max. Frame Rate DirectIP™ Modus : 30ips : 3840 x 2160 15ips : 3840 x 2160(WDR)
Supports Resolutie DirectIP™ Modus : 3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360
Multi-Video Streaming DirectIP™ Modus : Quadruple streaming
Netwerk Protocollen DirectIP™ Modus : Direct IP 2.0 Protocol, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP
Beveiliging DirectIP™ Modus : SSL Encryptie, Multi-User Authority, IEEE 802.1x
IP Filtering, HTTPS
Remote Access Client DirectIP™ Modus : DirectIP™ NVR connectie, IDIS Web, IDIS Mobile (Plus), IDIS Solution Suite, IDIS Cloud Manager
Ethernet RJ45(10/100BASE-T)
Opnamesessie Buffer (NLTSrec) Ja (tot 60MB)
Edge Opslag micro SD/SDHC/SDXC, Smart Failover (tot 256GB)
Alarm & Event
Trigger Event Motion Detectie, Alarm in, Audio detectie, Tampering, TripZone
Event Notificatie Remote S/W, Email (met plaatje)
Audio In/ Uit 1 / 1
Alarm In / Uit 1 / 1
Omgeving
Vandaalbestendig IK10
Out-door Ready IP67, Heater
Bedrijfstemperatuur -40°C ~ +55°C (-40°F ~ +131°F)
*Opstarten boven -20°C (-4°F)
Bedrijfsvochtigheid 0% ~ 90%
Elektrisch
Voeding 12VDC, PoE(IEEE 802.3af class 3)
Stroomverbruik 12V=, 1,2A, 14,4W PoE, IEEE 802.3af(Class 3), 12,4W
Goedkeuring FCC, CE, KC
Mechanisch
Afmetingen (Ø x H) Ø155 x 104,4mm
Gewicht 1,02 kg

Informations complémentaires

Caméra: Ouverture

Caméra: BLC / WDR

,

Enregistreur / Caméra: Compression

, ,

Caméra: Jour & Nuit

Caméra: Distance focale

Caméra: IR distance

Caméra: Type de lentille

Caméra: Résolution maximale

Caméra: Extérieure

,

Caméra: Montage

Téléchargements

Firmware
Dernière version
Manuel NL EN FR
Guide rapide
Manuel d’installation
Mode d’emploi
Fiche technique NL EN FR
Dernière version
A&E specifications NL EN FR
Architectural and Engineering Specifications
BIM
Modèle d’information du bâtiment

Dimensions

DC-D4831HRX afmetingen
