Video |
Beeld Sensor | 1/3″ CMOS |
Max. Resolutie | 1920 x 1080 |
Scanning Mode | Progressive Scan |
Lens type | Motoriseerde Vari-focal |
Brandpuntsafstand | f=2.8 – 12mm |
Opening | F=1.6 – 2.7 |
Iris Control | P-Iris |
Kijkhoeken | Wide : 98º(H), 52º(V), 116º(D) Tele : 33º(H), 18,5º(V), 37,9º(D) |
Pan/Tilt Range | Pan: -176° ~ 176°, Tilt: 0° ~ 66°, Rotate: -90° ~ 90° |
Min. Verlichting | KLEUR : 0.1 lux @ F1.6 Z/W : 0.01 lux @ F1.6 |
S/N Ratio | Meer dan 45dB |
Dynamische Range | 120dB (True WDR) |
Electronische Shutter Snelheid | Auto / Handmatig (1/30 ~ 1/10000), Anti-Flicker, Slow Shutter( 1 ~ 1/5, 1/7.5, 1/15) |
Dag & Nacht | IR cut filter met automatische schakelaar |
IR Afstand (LEDs) | – |
Beeldinstelling | Instelbare Exposure, Witbalans, Scherpte |
Digital Ruisonderdrukking | Instelbaar 2DNR/3DNR |
Backlight Compensatie | Aan / Uit / HSBLC |
Mirroring / Pivot | Horizontaal / Verticaal / Pivot |
Beeld stabilisatie | – |
De-fog | Aan / Uit |
Privacy Masker | 8 Zones |
Intelligent Video | Video Motion Detectie, Active Tampering Alarm, Trip Zone |
Video Uit | 1 BNC(Accessoire) |
Netwerk |
Video Compressie | H.264(MP), M-JPEG, H.265 |
Intelligent Codec | Ondersteund |
Bitrate Control | H.264 – CBR/ VBR, H.265 – CBR / VBR |
Audio Compressie | ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law |
Two-way Audio | Ja |
IP Camera Protocol | DirectIP™ Modus : DirectIP |
| Compatibiliteit Modus : IDIS ONVIF Profile S |
Max. Frame Rate | DirectIP™ Modus : 30ips : 1920 x 1080(WDR) |
| Compatibiliteit Modus : 60ips : 1920 x 1080 30ips : 1920 x 1080(WDR) |
Supports Resolution | DirectIP™ Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
| Compatibiliteit Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
Multi-Video Streaming | DirectIP™ Modus : Quadruple streaming |
| Compatibility Mode : Quadruple streaming |
Netwerk Protocollen | DirectIP™ Modus : Direct IP Protocol |
| Compatibiliteit Modus : RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
Beveiliging | DirectIP™ Modus : SSL Encryptie |
| Compatibiliteit Modus : Multi-User Authority, IEEE 802.1x IP Filtering, HTTPS, SSL Encryptie |
Remote Access Client | DirectIP™ Mode : DirectIP™ NVR connection |
| Compatibiliteit Modus : IDIS Web, IDIS Mobile, IDIS Solution Suite |
Ethernet | RJ45(10/100BASE-T) |
Opnamesessie Buffer (NLTSrec) | Ja (tot 60MB) |
Edge Opslag | micro SD/SDHC/SDXC, Smart Failover (tot 128GB) |
Alarm & Event |
Trigger Event | Motion Detectie, Alarm in, Audio detection, Tampering, TripZone |
Event Notificatie | Remote S/W, Email (met plaatje) |
Audio In/ Uit | Line-in 1ea / Line-out 1ea |
Alarm In / Uit | Ingang 1ea / Uitgang 1ea |
Omgeving |
Vandaalbestendig | – |
Outdoor Ready | – |
Bedrijfstemperatuur | -10°C ~ 50°C ( 14°F ~ 122°F) *Opstarten boven 0°C (32°F) |
Bedrijfsvochtigheid | 0% ~ 90% |
Elektrisch |
Voeding | 12VDC, PoE(IEEE 802.3af class 2) |
Stroomverbruik | 12V= 0,47A, 5,64W PoE, IEEE 802.3af(Class 2) |
Goedkeuring | FCC, CE, KC |
Mechanisch |
Afmetingen (Ø x H) | Ø174mm x 122.4mm (Ø6,85″ x 4,82″) zichtbaar: Ø174mm x 70.7mm (Ø6,85″ x 2,78″) |
Gewicht | 0,71 kg |
