Video |
Beeld Sensor | 1/2.9″ CMOS |
Max. Resolutie | 1920 x 1080 |
Scanning Mode | Progressive Scan |
Lens type | Fixed-focal |
Brandpuntsafstand | f=4.0mm |
Opening | F2.0 |
Iris Control | Fixed Iris |
Kijkhoeken | 84.4º(H), 50.3º(V), 104.6º(D) |
Pan/Tilt Range | Pan: -180° ~ 174°, Tilt: 0° ~ 65° |
Min. Verlichting | Kleur : 0.2 lux F2.0 Z/W : 0 lux (IR LED aan) |
S/N Ratio | 31.2 dB |
Dynamische Range | 74.7 dB |
Electronische shutter snelheid | Auto / Handmatig (1/30 ~ 1/8000), Anti-Flicker, Slow Shutter(1/7.5,1/15) |
Dag & Nacht | IR cut filter met automatische schakelaar |
IR Afstand (LEDs) | 15 m (2 ea) |
Beeld Instelling | Instelbare Exposure, Witbalans, Scherpte |
Digitale Ruisonderdrukking | Instelbaar 2DNR |
Backlight Compensatie | Aan/ Uit / HSBLC |
Mirroring / Pivot | Horizontaal / Verticaal / Pivot |
Privacy Masker | 16 Zones |
Intelligent Video | Video Motion Detectie, Active Tampering Alarm, Trip Zone |
Video Uit | 1 BNC(Accessoire) |
Netwerk |
Video Compressie | H.264(MP), M-JPEG |
Intelligent Codec | – |
Bitrate Control | H.264 – CBR / VBR |
Audio Compressie | – |
Two-way Audio | – |
IP Camera Protocol | DirectIP™ Modus : DirectIP |
| Compatibiliteit Modus : IDIS ONVIF Profile S |
Max. Frame Rate | DirectIP™ Modus : 30ips : 1920 x 1080 |
| Compatibiliteit Modus : 30ips : 1920 x 1080 |
Ondersteunt Resolutie | DirectIP™ Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
| Compatibiliteit Modus : 1920×1080, 1280×720, 704×480, 640×360, 352×240 |
Multi-Video Streaming | DirectIP™ Modus : Quadruple streaming |
| Compatibiliteit Modus : Triple streaming |
Netwerk Protocollen | DirectIP™ Modus : Direct IP Protocol |
| Compatibiliteit Modus : RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
Beveiliging | DirectIP™ Modus : SSL Encryptie |
| Compatibiliteit Modus : Multi-User Authority, IEEE 802.1x IP Filtering, HTTPS, SSL Encryptie |
Remote Access Client | DirectIP™ Modus : DirectIP™ NVR connectie |
| Compatibiliteit Modus : IDIS Web, IDIS Mobile, IDIS Solution Suite |
Ethernet | RJ45(10/100BASE-T) |
Recording Session Buffer (NLTSrec) | Ja (tot 60MB) |
Edge Opslag | micro SD/SDHC, Smart Failover (tot 32GB) |
Alarm & Event |
Trigger Event | Motion Detection, Tampering, TripZone |
Event Notificatie | Remote S/W, Email (met plaatje) |
Audio In/ Uit | – |
Alarm In / Uit | – |
Omgeving |
Vandaalbestendig | IK10 |
Outdoor Ready | IP66 |
Bedrijfstemperatuur | -10°C ~ 50°C ( 14°F ~ 122°F) *Opstarten boven 0°C (32°F) |
Bedrijfsvochtigheid | 0% ~ 90% |
Elektrisch |
Voeding | 12VDC, PoE(IEEE 802.3af class 2) |
Stroom verbruik | 3,96W |
Goedkeuring | FCC, CE, KC |
Mechanisch |
Afmetingen (Ø x H) | Ø155,1 x 86,2mm |
Gewicht | 0,7 kg (1,54lb) |
